| Product Specifications |
| Brand number | Thickness (mm) | Iron loss
(P1.7/50, W/kg) | Magnetic induction strength (B800, T) | Application areas |
| 27Q120 | 0.27 | ≤1.20 | ≥1.88 | Mid- and low-end transformers, small transformers |
| 27Q110 | 0.27 | ≤1.10 | ≥1.88 | Mid-range transformers, distribution transformers |
| 27Q105 | 0.27 | ≤1.05 | ≥1.88 | High-end transformers, high-efficiency energy-saving transformers |
{}
